| #! /usr/bin/python
from PIL import Image
import numpy
from fractions import gcd
from functools import reduce
import random
import sys
# file meta data
__version__ = "1.0"
__author__ = "abgoyal"
__license__ = "apl"
## some utilities
#sort a 2d list by a given column #
rev_sortbycolumn = lambda l,c: sorted(l, key = lambda x: x[c], reverse=True)
sortbycolumn = lambda l,c: sorted(l, key = lambda x: x[c])
# vector gcd
vgcd = lambda v: reduce(gcd,v)
## algo implementations
# distance metric - this it the key
def distance(v1, v2): # fractional difference in pixel values
return numpy.sum(((v1-v2)/(v1+v2+1))**2)
# simple cluster detection
def cluster1d(values):
z = sortbycolumn(values, 1)
part = [ z.pop()[0]]
while vgcd(part)>1:
part.append(z.pop()[0])
return vgcd(part[:-1])
# estimate the strip width
def stripwidth_algo(im):
#extract image pixel data as a numpy array
image_data = numpy.asarray(im.convert("L").getdata(), 'float')
image_width = im.size[0]
image_height = im.size[1]
image_column = lambda i: (image_data[i::image_width])
# calculate correlation coefs between each pair of adjacent columns in the image
dists = [ [i+1, distance(image_column(i), image_column(i+1))] for i in xrange(0,image_width-1) ]
return cluster1d(dists)
# unshred an image given strip width
def unshred_algo(im,strip_width):
im_width= im.size[0]
im_height = im.size[1]
n = im_width/strip_width # number of strips
# extract grayscale pixel data from image into a numpy.array
image_data = numpy.asarray(im.convert("L").getdata(), 'float')
# extracts all pixels from a specific column
image_column = lambda i: (image_data[i::im_width])
# extract the left and right edges of each strip as columns
left_edges = []
right_edges = []
for i in xrange(0,n):
left_edges.append(image_column(i*strip_width))
right_edges.append(image_column(i*strip_width + strip_width -1))
# calculate the distance metric between each left-edge<>right-edge pair
dists = []
for left_edge_index,left_edge in enumerate(left_edges):
for right_edge_index,right_edge in enumerate(right_edges):
if not left_edge_index == right_edge_index: # a strip cannot be next to itself
dists.append([left_edge_index, right_edge_index, distance(left_edge,right_edge) ])
sorted_dists = rev_sortbycolumn(dists,2)
# select the pairs with the least distance between (strip_left_edge, strip_right_edge) pixels
assigned_left_edges = []
assigned_right_edges = {}
while len(assigned_right_edges)<n:
left_edge_index, right_edge_index, dist = sorted_dists.pop()
if (right_edge_index not in assigned_right_edges) and (left_edge_index not in assigned_left_edges):
assigned_right_edges[right_edge_index] = left_edge_index
assigned_left_edges.append(left_edge_index)
# last strip assigned is most probably the left edge
s = assigned_left_edges[-1]
order = [ s ]
while s in assigned_right_edges and len(order)<n:
order.append(assigned_right_edges[s])
s = assigned_right_edges[s]
return order
def strip_copy(im_original, im_copy, w, a, b):
h = im_original.size[1]
a_tuple= tuple([a*w, 0, (a+1)*w, h])
b_tuple= tuple([b*w, 0, (b+1)*w, h])
im_copy.paste( im_original.crop(a_tuple) , box=b_tuple )
def unshred(im,strip_width=None):
im2 = im.copy()
# if strip width not given, try to calculate it
if not strip_width:
strip_width = stripwidth_algo(im)
order = unshred_algo(im,strip_width)
for i,j in enumerate(order):
strip_copy(im, im2, strip_width, j, i)
return im2
def shred(im,m):
im_width= im.size[0]
im_height = im.size[1]
im2 = im.copy()
n = im_width/m
strips = range(0,n)
random.shuffle(strips)
for f,t in enumerate(strips):
strip_copy(im, im2, m, f, t)
return im2
def demo():
im_shreded = Image.open("TokyoPanoramaShredded.png")
im_fixed1 = unshred(im_shreded)
im_fixed1.show()
im_fixed2 = unshred(im_shreded,32)
im_fixed2.show()
im_reshredded = shred(im_fixed2, 16)
im_fixed1 = unshred(im_shreded)
im_fixed1.show()
im_fixed2 = unshred(im_shreded,16)
im_fixed2.show()
def process_command(args):
cmd = args[0]
if cmd == "shred":
w = int(args[1])
ifname = args[2]
ofname = args[3]
im = Image.open(ifname)
im_shredded = shred(im, w)
im_shredded.save(ofname)
return
if cmd == "unshred":
w = int(args[1])
ifname = args[2]
ofname = args[3]
im = Image.open(ifname)
if w==0:
im_fixed = unshred(im)
else:
im_fixed = unshred(im,w)
im_fixed.save(ofname)
return
print "Unknown command"
return
if __name__ == "__main__":
if len(sys.argv) > 1:
process_command(sys.argv[1:])
else:
demo()
|
